RF40 AM/RL CD G150

Spare parts for

RF40 AM/RL CD G150

Don't mix up spare parts! The new generation of Ringfeder couplings are fundamentally redesigned. Accordingly, also spare parts are redesigned to comply with the new generation. Even if some old parts seemingly fit, they must not be used for new generation couplings as this may jeopardise product operation and safety!
RF40 AM/RL CD G150
123a3b4567a7b111515a182324252626d26i26j32a32b363738394042434452
Click and drag to navigate the image

RF40 AM/RL CD G150

×

No hits. Empty

  • Repair kit RF40/45 AM

    1 Repair kit RF40/45 AM

    15990728

    View details

  • Top guide bushing RF 40/45

    2 Top guide bushing RF 40/45

    15990735

    View details

  • Coupling body RF40/45

    3a Coupling body RF40/45

    15990985

    View details

  • Coupling body RF40/45

    3b Coupling body RF40/45

    15990713

    View details

  • Safety device RF40/45/50

    4 Safety device RF40/45/50

    15990739

    View details

  • RINGFEDER CSM DIN 72585 - Coupling sensor module

    5 RINGFEDER CSM DIN 72585 - Coupling sensor module

    15990856

    View details

  • Bottom guide bushing RF40/45

    6 Bottom guide bushing RF40/45

    15990732

    View details

  • Synthetic wear plate (kit) xx40

    7a Synthetic wear plate (kit) xx40

    06998771

    View details

  • Casted wear plate (kit) xx40

    7b Casted wear plate (kit) xx40

    14994503

    View details

  • Return spring kit RF40/45/50

    11 Return spring kit RF40/45/50

    15990751

    View details

  • Hand & locking lever kit RF40 AM

    15 Hand & locking lever kit RF40 AM

    15990761

    View details

  • Hand lever AM

    15a Hand lever AM

    15990745

    View details

  • Spring holder

    18 Spring holder

    07998341

    View details

  • Coupling bolt RF40/45 AM

    23 Coupling bolt RF40/45 AM

    15990749

    View details

  • Lubrication plug 10 pcs

    24 Lubrication plug 10 pcs

    15990758

    View details

  • Locking spring xx50 A/B/AM, xx40/xx45 AM

    25 Locking spring xx50 A/B/AM, xx40/xx45 AM

    14991273

    View details

  • AM unit, complete for xx40 AM

    26 AM unit, complete for xx40 AM

    14991246

    View details

  • Plastic plug for AM unit (10 pcs.)

    26d Plastic plug for AM unit (10 pcs.)

    15990759

    View details

  • Membrane kit AM

    26i Membrane kit AM

    14991245

    View details

  • Coiled spring pin 32x10 ISO 8750

    26j Coiled spring pin 32x10 ISO 8750

    14991269

    View details

  • Screw kit, Cover plate

    32a Screw kit, Cover plate

    15990899

    View details

  • Screw kit, Cover plate

    32b Screw kit, Cover plate

    14991359

    View details

  • Rubber spring kit xx40 G145/G150, xx50 G4/G5

    36 Rubber spring kit xx40 G145/G150, xx50 G4/G5

    14991672

    View details

  • Push washer xx40 G145/G150, xx50 G4/G5/GX/CX

    37 Push washer xx40 G145/G150, xx50 G4/G5/GX/CX

    07995520

    View details

  • Drawbar guide complete RF 40/50 G150/G5

    38 Drawbar guide complete RF 40/50 G150/G5

    14991296

    View details

  • Bearing bush kit  xx40 G145/G150, xx50 G4/G5

    39 Bearing bush kit xx40 G145/G150, xx50 G4/G5

    14991304

    View details

  • Pull washer  xx40 G145/G150, xx50 G4/G5/GX/CX

    40 Pull washer xx40 G145/G150, xx50 G4/G5/GX/CX

    07995555

    View details

  • Castellated nut M45 X 3

    42 Castellated nut M45 X 3

    06997732

    View details

  • Cotter pin 8 X 80 for M45

    43 Cotter pin 8 X 80 for M45

    12991533

    View details

  • Protecting cap G150/G145/G4/G5/CX

    44 Protecting cap G150/G145/G4/G5/CX

    10991323

    View details

  • Axle with locking lever RF40/45

    52 Axle with locking lever RF40/45

    15990725

    View details
